Chuck Size	ø 254 mm
N. Stations In The Turret	10
Spindle Nose	JIS A2-6
N. Spindle Speed	24-2400RPM
Spin Motor Power	15kW
Minimum Cycle Of Portal	n.d.
Piece Size	n.d.
Piece Weight	n.d.
Machine Weight	4,000 kg

Chuck Size	ø 210 mm
N. Stations In The Turret	15 x 2
Spindle Nose	ASA 6"
N. Spindle Speed	33-3500RPM
Spin Motor Power	18kW x 2
Minimum Cycle Of Portal	62 sec. / 2 pz.
Piece Size	ø 220 mm x 170 mm L
Piece Weight	8.0 kg x 2
Machine Weight	13,000 kg

Chuck Size	ø 254 mm
N. Stations In The Turret	10 x 2
Spindle Nose	JIS A2-6
N. Spindle Speed	20-2000RPM
Spin Motor Power	11kW
Minimum Cycle Of Portal	25 sec.
Piece Size	ø 200 mm x 100 mm L
Piece Weight	8.0 kg x 2
Machine Weight	7,000 kg

Chuck Size	ø 210 mm
N. Stations In The Turret	10 x 1
Spindle Nose	JIS A2-5
N. Spindle Speed	45-4500RPM
Spin Motor Power	7,5kW
Minimum Cycle Of Portal	15 sec.
Piece Size	ø 120 mm x 80 mm L
Piece Weight	3.0 kg x 2
Machine Weight	2,500 kg

Chuck Size	ø 165 mm
N. Stations In The Turret	8 x 2
Spindle Nose	ASA 5"
N. Spindle Speed	60-6000RPM
Spin Motor Power	5,5kW x 2
Minimum Cycle Of Portal	11 sec
Piece Size	ø 60 mm x 40 mm L
Piece Weight	0.7 kg x 2
Machine Weight	3,500 kg

Chuck Size	ø 165 mm
N. Stations In The Turret	8 x 2
Spindle Nose	ASA 5"
N. Spindle Speed	60-6000RPM
Spin Motor Power	5,5kW x 2
Minimum Cycle Of Portal	16 sec
Piece Size	ø 60 mm x 40 mm L
Piece Weight	0.7 kg x 2
Machine Weight	3,500kg
